MB QUART ONX1.2000D 2000W CLASS D MONOBLOCK AUDIO AMPLIFIER ONX11500 (RM1700)
MB Quart ONYX Series Monoblock Class D Car Power Amplifier system
Power Rating:
650W RMS x 1 @ 4 Ohms
1300W RMS x 1 @ 2 Ohms
2000W RMS x 1 @ 1 Ohms
PWM (Pulse Width Modulated) MOSFET power supply design
MB QR-2 Wired remote bass level control included
LED power (green) and protect (red) indicators features
Variable Bass Boost (0 to +10 dB bass boost at 45 Hz
Mono channel operation
Dual speaker terminals simplify the hookup of multiple speakers
Preamp RCA outputs to daisy chain multiple amps
4-Way System Protection circuitry (DC, thermal, overload, and speaker short protection)
Piano black gloss finish with illuminated logo
Heavy duty aluminum alloy convection heatsink design for superb heat dissipation
Silver-plated RCA level inputs
Silver-plated screw terminals
Input sensitivity:
Low level: 200mV-6V
Provides Variable low-pass filter (30-250 Hz, 24 dB/octave)
Subsonic filter (24 dB at 15-35 Hz)
Damping factor: >200
Frequency response: 15-250 Hz
Dimensions: 14-7/8"L x 9"W x 2-1/2"H
2-gauge power and ground wiring is required for installation
